Aramid Insulated Flexduct with Coil Spring Support

MATERIALS

• 4 ply
• G82 Silicone outer
• 2 layers of aramid Inner ply
• Fiberglass insulation
• Aramid cuffs

MAXIMUM OPERATING TEMPERATURE

•  500°F (260°C)

FEATURES

• Medium temperature applications
• High flexibility
• Aramid cloth inner is extremely abrasion resistant
• Made to order  per customer specs
• Accommodates for thermal movement
• Accommodates for vibration
• Non-Flammable
• Made in the USA

INDUSTRIES

• Pollution control
• Turbine and engine
• OEM

APPLICATIONS

• Conveying hot exhaust gases
• Accommodating for thermal expansion/contraction
• Highly abrasive environments
